CQR Hold-up PA Double Push Panic Button User Manual

1. הקדמה

מדריך זה מספק הוראות מקיפות להתקנה, הפעלה ותחזוקה של CQR Hold-up PA Double Push Panic Button. This device is designed to provide a reliable and immediate alert in emergency situations, integrating seamlessly with compatible alarm control panels. It features a double-press activation mechanism and a key-reset function to prevent accidental activation and ensure secure operation.

אנא קרא מדריך זה בעיון לפני ההתקנה והשימוש כדי להבטיח תפקוד ובטיחות תקינים.

2. מידע בטיחות

• בטיחות חשמל: Installation should only be performed by qualified personnel in accordance with all local and national electrical codes. Ensure power to the alarm control panel is disconnected before wiring.
• הַרכָּבָה: Mount the device securely on a stable surface to prevent accidental dislodgement.
• סְבִיבָה: Do not expose the device to extreme temperatures, humidity, or direct water. It is designed for indoor use only.
• תַחזוּקָה: אל תנסה לפתוח או לתקן את המכשיר בעצמך. יש לפנות לכל טיפול וטיפול באנשי שירות מוסמכים.
• בּוֹחֵן: Regularly test the panic button's functionality in conjunction with your alarm system to ensure it is operating correctly.

3. תכולת החבילה

ודא שכל הפריטים המפורטים להלן נמצאים בחבילה שלך:

• CQR Hold-up PA Double Push Panic Button Unit
• Key for Reset Function
• Mounting Screws (may vary)
• מדריך למשתמש זה

4. התקנה והתקנה

The CQR Hold-up PA Double Push Panic Button is designed for surface mounting and integration with a compatible alarm control panel.

4.1. מיקום הרכבה

Choose a discreet yet easily accessible location for mounting, such as under a counter, desk, or near a point of sale. Ensure the surface is clean, dry, and structurally sound.

4.2. Wiring to Alarm Control Panel

1. נתק חשמל: Before beginning any wiring, ensure the alarm control panel is completely powered off and disconnected from its main power source and backup battery.
2. Access Wiring Terminals: פתח את ה-casing of the panic button (if applicable) to expose the wiring terminals. Refer to your alarm control panel's manual for specific zone input terminals for panic devices.
3. חיבור חוטים: Connect the panic button's output wires to the designated panic zone input terminals on your alarm control panel. This device typically operates as a Normally Closed (NC) contact, opening upon activation. Consult the wiring diagram provided with your alarm control panel for correct polarity and connection points.
4. חיווט מאובטח: ודא שכל חיבורי החוטים מאובטחים ומבודדים כראוי.
5. סגור ג'asing: Carefully close the panic button casing.

4.3. הרכבת היחידה

1. מארק חורים: Use the panic button unit as a template to mark the drilling locations for the mounting screws on your chosen surface.
2. לקדוח חורים של טייס: Drill pilot holes if necessary, appropriate for the mounting screws.
3. מכשיר מאובטח: Align the panic button with the drilled holes and secure it firmly using the provided mounting screws. Do not overtighten.

4.4. Power On and Test

Once installation is complete, restore power to the alarm control panel. Perform a functional test of the panic button as described in the "Operating Instructions" section to ensure it triggers the alarm system correctly.

5. הוראות הפעלה

5.1. Activating the Panic Button

To activate the panic alarm, simultaneously press both red push buttons on the front of the unit. The double-press mechanism is designed to minimize accidental activations while ensuring quick response in an emergency.

Upon successful activation, the panic button will latch, and the alarm control panel will initiate the programmed panic response (e.g., siren activation, silent alarm, notification to monitoring station).

5.2. Resetting the Panic Button

After activation, the panic button will remain in a latched state until manually reset. To reset the device:

1. Insert the provided key into the keyhole located on the top surface of the panic button.
2. Turn the key clockwise (or counter-clockwise, depending on the specific mechanism) until the buttons release and return to their original position.
3. Remove the key. The panic button is now reset and ready for re-activation.

חָשׁוּב: Always keep the reset key in a secure and accessible location known only to authorized personnel.

6. תחזוקה

The CQR Hold-up PA Double Push Panic Button requires minimal maintenance to ensure reliable operation.

• ניקוי: Periodically wipe the exterior of the unit with a soft, dry cloth. Do not use abrasive cleaners, solvents, or excessive moisture.
• בּוֹחֵן: It is recommended to test the panic button's functionality at least once a month to confirm its connection to the alarm system and proper activation/reset.
• בְּדִיקָה: Visually inspect the unit for any signs of damage, loose wiring, or tampארינג.

7. פתרון תקלות

If you encounter issues with your CQR Hold-up PA Double Push Panic Button, refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact your alarm system installer or the manufacturer's technical support.

8. מפרטים

9. אחריות ותמיכה

Specific warranty information for the CQR Hold-up PA Double Push Panic Button is not provided within this manual. For details regarding warranty coverage, terms, and conditions, please refer to the documentation included with your purchase or contact the retailer or manufacturer directly.

For technical support, installation assistance, or troubleshooting beyond the scope of this manual, please contact your alarm system installer or the manufacturer, Security Components LTD, through their official channels.
