JIMIMAX JC171 DMS Camera User Manual

1. הקדמה

The JIMIMAX JC171 Driver Monitoring System (DMS) Camera is an accessory designed to enhance safety when paired with the JIMIMAX JC261 Dashcam. This camera utilizes advanced AI algorithms to monitor driver behavior, detecting signs of fatigue and distraction to promote safer driving practices.

This manual provides essential information for the proper installation, operation, and maintenance of your JC171 DMS Camera. Please read it thoroughly before use.

2. תכולת החבילה

אנא ודא שכל הפריטים נמצאים בחבילה:

• JIMIMAX JC171 DMS Camera
• תושבת הרכבה (מחוברת מראש או נפרדת)
• סרט דביק דו צדדי
• מדריך מהיר

Note: The JC261 Dashcam is not included with this package and must be purchased separately. This device is only compatible with the JC261 model, not JC261P.

3. המוצר נגמרview

The JC171 DMS Camera is a compact unit designed for discreet installation within the vehicle cabin. It features a built-in speaker for audible alerts and infrared night vision capabilities.

איור 1: צד קדמי view of the JIMIMAX JC171 DMS Camera.

תכונות עיקריות:

• Driver Monitoring System (DMS): Detects fatigue (e.g., yawning) and distracted driving (e.g., texting, smoking, fiddling with stereo), as well as instances where the driver is not in position.
• Visual AI Algorithms: Incorporates AI for ADAS (Advanced Driver-Assistance Systems) and DMS functionalities to enhance road and driver safety.
• Highly-Integrated Design: Small form factor with an integrated speaker for immediate audible alerts.
• ראיית לילה אינפרא אדום: Equipped with IR-940 LEDs to capture clear images in low-light conditions without causing glare to the driver.

4. התקנה והתקנה

Proper installation is crucial for the optimal performance of the DMS camera.

4.1 הרכבת המצלמה

1. בחר מיקום: Select a position on your vehicle's windshield or dashboard that provides a clear, unobstructed view of the driver's face and upper body. Ensure it does not obstruct the driver's view של הכביש.
2. נקה את המשטח: Thoroughly clean the chosen mounting surface with an alcohol wipe and allow it to dry completely. This ensures strong adhesion.
3. דבק דבק: Apply the supplied double-sided adhesive tape to the base of the camera's mounting bracket.
4. אבטח את המצלמה: Firmly press the camera with the attached adhesive onto the cleaned surface. Hold for at least 30 seconds to ensure a secure bond.
5. התאם זווית: Adjust the camera angle to ensure it is directed towards the driver's face. The camera should be able to clearly see the driver's eyes and head movements.

4.2 Connecting to JC261 Dashcam

The JC171 DMS Camera connects directly to your JIMIMAX JC261 Dashcam. Refer to your JC261 Dashcam's manual for specific port locations and connection procedures. Typically, the DMS camera connects via a dedicated port on the main dashcam unit.

• Ensure the dashcam is powered off before connecting the DMS camera.
• Carefully insert the connector into the designated port on the JC261 Dashcam.
• Route the cable neatly to avoid interference with driving controls or visibility.

5. הוראות הפעלה

Once connected and powered on with the JC261 Dashcam, the JC171 DMS Camera operates automatically.

5.1 Driver Monitoring Functionality

The DMS camera continuously monitors the driver for specific behaviors:

• Fatigue Detection: Identifies signs of drowsiness, such as prolonged eye closure (yawning).
• Distraction Detection: Recognizes common distractions, including texting, smoking, or excessive interaction with in-car systems.
• Driver Position Monitoring: Alerts if the driver is not properly positioned or looking at the road.

Figure 2: Visual representation of the DMS camera detecting various driver behaviors.

5.2 Audible Alerts

When a detected behavior triggers an alert, the built-in speaker will emit an audible warning. These alerts are designed to promptly notify the driver to re-focus on the road or take a break if fatigued.

5.3 ראיית לילה אינפרא אדום

The integrated IR-940 LEDs automatically activate in low-light conditions, ensuring the camera can maintain clear monitoring capabilities at night without emitting visible light that could distract the driver.

6. תחזוקה

To ensure the longevity and optimal performance of your JC171 DMS Camera, follow these maintenance guidelines:

• ניקוי העדשה: נגבו בעדינות את עדשת המצלמה בעזרת מטלית רכה ונטולת סיבים. במקרה של כתמים עקשניים, נגבו קלותampשטפו את המטלית במים או בתמיסת ניקוי עדשות. הימנעו מחומרים שוחקים או כימיקלים חזקים.
• ניקוי הגוף: השתמש יבש או מעט דamp cloth to clean the camera body. Do not allow water or liquids to enter the device.
• תנאים סביבתיים: Avoid exposing the camera to extreme temperatures, direct sunlight for prolonged periods when not in use, or excessive moisture.
• בדיקת כבלים: בדקו מעת לעת את כבל החיבור לאיתור סימני בלאי, נזק או חיבורים רופפים.

7. פתרון תקלות

If you encounter issues with your JC171 DMS Camera, refer to the following common problems and solutions:

• המצלמה לא מופעלת:
  • Ensure the JC261 Dashcam is powered on and functioning correctly.
  • Check the connection cable between the DMS camera and the dashcam for secure attachment.
  • Verify that the cable is not damaged.
• DMS Not Detecting Driver Behavior:
  • Confirm the camera lens is clean and free from obstructions.
  • Ensure the camera is properly aimed at the driver's face and upper body. Adjust the mounting angle if necessary.
  • Verify that no objects are blocking the camera's field of view.
• Unclear Night Vision:
  • נקה את עדשת המצלמה.
  • Ensure there are no external light sources directly interfering with the IR LEDs.
• Audible Alerts Not Functioning:
  • Check the volume settings on your JC261 Dashcam, if applicable.
  • Ensure the camera's built-in speaker is not obstructed.

If the problem persists after attempting these solutions, please contact JIMIMAX customer support.

8. מפרטים

9. אחריות ותמיכה

For information regarding warranty coverage, technical support, or service inquiries, please refer to the warranty card included with your product or visit the official JIMIMAX website. You may also contact JIMIMAX customer service directly for assistance.

Please have your product model (JC171) and purchase information ready when contacting support.
